New from the vault

If like us, you’ve been busy spending your time working (building surveys, helping clients, upgrading software, reading logs, …), you may not have had a chance to keep up with the latest tips & tricks from our Help Centre. Feel free to have a flick through our latest picks:

Design & Analyse FAQs

Your first steps with Askia’s range of software are now even smoother! The askiadesign & askiaanalyse FAQs will help cover your needs when start building your first questionnaire or analysing your first survey results.

Askia analyse FAQ screenshot

Access the Design FAQ and/or the Analyse FAQ to take a look!

How to import / export Askiavista projects

Upgrading your Askiavista server environment? Using a staging server before deploying your Askiavista projects to your live environment? Look no further, this article walks us through the simple steps of using AskiaVista Tool to import and/or export Askiavista projects from one server to another.

AskiaVista Tool screenshot

This nifty application allows AskiaVista administrators to manage the import / export of Vista project related components: Portfolios, Filters, Weightings, Profiles, Calculated variables, Chart templates, Table styles, …

Check out the full article for more details.

Web survey link encryption

As from version 5.3.5, we’ve had the ability to send survey links with URL encryption / prettyfying. Up until now, encryption could only be achieved manually and was only reserved for StartSurvey link type. We have therefore created a script which allows you to encrypt survey links by batch, based on a CSV file. With this script, you can encrypt many URLs at once.

Therefore, a standard DoExternalPanel link with some extra parameters looks like:

http://mydomain.com/WebProd/cgi-bin/askiaext.dll?Action=DoExternalPanel&SurveyName=fullurl&Broker=askia&BrokerPanelId=4&tT=ad

And the encrypted version would return a URL like:

http://mydomain.com/WebProd/~jgAqch8-_cm6F4j1VIJMvSW8l_cYjUaX

Vista API tutorial

This article is a followup to the first API tutorial, it showcases a series of bite-sized examples to highlight important features of the Vista API.

askiavista API tutorial illustration

This extensive tutorial covers all the basics for Vista API development through 11 examples that feature such concepts as: displaying a cross-tab via the getPages method, securing your dashboard with a login page, grouping multiple requests to improve load management and client-side performance, retrieving a list of questions and/or responses via the askiavista.getQuestions and the askiavista.getResponses methods, adding a dropdown menu to your dashboards, … and many more!

Using Amazon S3 for resource uploads for Askiaface on iOS/Android

Using an external service to automatically upload your survey’s media captured on your iOS and/or Android devices is a very convenient way to centralise all such assets and a great method of securing all such resources.

This article covers all the steps from setting up your Amazon S3 account, checking all S3 settings and prepping your survey’s media capture questions in order to automate the upload of all media content.

Read the article for the full picture!

Askiavista is really growing!

Update: we have updated askiavista to version 6.0.3.5, read more about it!

Yup, askiavista is nearly a grown-up! But because it’s an Askia application, it’ll always be a bit childish 😉 .

We are unleashing the latest update to askiavista, version 6.0.3.4; this latest release is packed with several nifty features and some squashed bugs:

Single Sign-On

We introduced SSO compatibility a couple of years ago but this useful feature has finally made it through to version 6! For this, we have introduced a new web service, AskiaVistaSSO, that is in charge of:

  • creating a unique & secure TrustKey
  • sending the TrustKey to AskiaVista Manager
  • authorises the user to connect or not to askiavista

Check the full details on this.

Replay multiple queries simultaneously

AskiaVista API’s Replay Plugin allows developers to replay a given query with few changes; it’s specially useful for cross-tab queries that produce tables or charts.

Let’s imagine you have a dropdown with the list of filters (sub-populations) from which the user can choose a given filter that will replay a table by applying it the selected filter.

The new version of the Replay plugin allows the developers/users to replay several tables or charts in one go.

So, when the user selects a filter it could be applied to multiple tables or charts at the same time.

In the background the Replay plugin uses a transaction to execute all queries in a single server-side call. The main benefit is to reduce the amount of bandwidth & queries between the client and the server.

Askia.config path now in the Registry

Up until now, the Askia.config file path was stored in IIS’  web.config file (a bit of an inception, eh?). Because any update could overwrite the web.config file, we often ended up with errors related to the configuration file not being found.

To improve this, askiavista searches the Askia.config path in the following order:

  1. In the directory of the current application
  2. If not found, it searches for the web.config as usually
  3. If not found, it search in the Registry

Read the feature request for more information.

Bug fixes

Finally, we have also fixed some outstanding issues in askiavista 6.0.3.4, check below for the most important ones:

  • Empty table when deactivating all calculations for tables (#6349)
  • Calculated responses not copied when copy/paste presentation (#6362)
  • Hidden responses displayed in xtab when moving variables around R/C/E (#6388)
  • Drag Drop filter is not applied to Excel export from a Portfolio (#6413)
  • Scaled-response questions are not treated as closed (#6421)
  • Cannot remove ‘Mean’ calculation caption from table and chart (#6455)
  • Total column and Edge inverted in the Property panel (#6476)
  • AskiaVistaManager can crash several times starting (#6483)

Oh, and did I mention that we have started to play with the amazing D3.js data visualisation library? It’s still just a playground but check this out! Thanks to Brice for his great work on that!

That’s all for now folks 😀

The Electric Kool-Aid Askia Test

Abstract: Survey scripting and coding have lots in common and we should bring testing techniques into Survey Design. For this we have improved Random Data Generation and created a new Tools module called “Script Verification”.

SurveyMonkey, Google consumer surveys and other disruptive DIY technologies have changed the Market Research industry. Any marketing director can put together an online survey, get sample from a number of panel providers and have results to their strategic questions in hours.

But Askia software is not designed for marketing directors. It has been conceived for survey specialists, scripters, data processors who design and analyse complex surveys – sometimes long, sometimes algorithmically challenging, over long periods of time and eventually collecting millions of records. And with our target audience in mind we are continually improving our range of software. We want any design to be achievable, any layout, any number of records. It would be an exaggeration to call it Big Data but let’s say we specialise in “Medium Data”.

On the subject of interview data, I will only mention that in the last 2 years we have completely overhauled our way of storing data in SQL Server (5.3.3) and a new compressed inverted data format (5.3.4). But I am digressing, the subject of this article is about methodologically managing complexity.

Managing complexity with Askia's survey software

The challenge with complexity is that it invariably leads to human errors, their number exponentially growing with size, harder to spot and often too late. The thing is we, as programmers, know about complexity. Askia software is made up of millions of lines of code and, as some of you may have fleetingly experienced, it sometimes breaks. And, believe it or not, we coders have an aspiration to perfection: we constantly try new methodological or technical ways of testing our software so it works smoothly the second we release it. But any program that does anything more than sorting three numbers is bound to break and we have to live with the fact that we will always deliver short of what we wished for – but hopefully learn from past mistakes.

Survey scripting is programming – unfortunately Market Research tools are a little bit behind (yes we are aware of our responsibility there). Our first version of Design in 1994 was attempting to mimic the revolution Visual Basic brought to the programming world in 1991. All basic functionalities were available in a Graphical User Interface. We made the layout WYSIWYG but we still allowed programming in event driven scripts but hidden from the interface. Our AskiaScript still has the traces of its ancestry with variables defined with Dim, For Next loops – I’ll admit that not everybody at Askia thinks it’s a good thing but that’s the price to pay for backwards compatibility.

Reusability & object-oriented programming by Askia

Reusability is the key to decrease development time and increase reliability. For programmers reusability is generally known as Object-Oriented Programming. In all of our software, we have tried to include reusable objects: Generations Settings and Internet options in askiadesign, Tab-templates and clones in Askiaanalyse, survey inheritance in askiasurf, libraries everywhere. Last but certainly not least we have created Askia Design Controls: we have enabled (advanced) users to generate the perfect HTML / JavaScript for each PC / tablet / mobile target whatever the browser, its version or its Operating System. ADCs encapsulate data, they are polymorphic (you can use them on different types of questions and browsers) and because they are open source, it’s up to you to give them inheritance.

There is another part of programming that we would like to bring to the Market Research industry: it’s testing – unit testing, integration testing, system testing. For the development of AskiaScript 2.0 we designed the tests before we wrote one line of code – this is called test-driven development (TDD). The number of bugs was minimal for a development of that size. Each time we found a fault, we added it to the list of tests to make sure it would never surface again in subsequent versions.

Test-driven development in survey design by Askia

Along with the spec of a survey, there should be a list of tests. These tests should be run by someone other than the survey scripter – and the tester should not peek into the routing coding. Different people will think differently ensuring your tests cover more defects.  We have put together a non-exhaustive list of tests:

  • Interview level: data presence for mandatory questions, skip routing testing, coherence between questions, testing links and response visibility.
  • Usability testing: testing each screen on every platform.
  • Aggregated testing: making sure quotas are respected, rotations are balanced, multiple questions have multiple responses.
  • System testing: ensuring the survey runs well on the server and that the data you produce is usable.

Long before considering a soft launch the simplest way to see if your survey runs correctly is to generate random data. You have two ways of doing so: either by using AskiaTools’ random data generator or using a JavaScript simulator (see here). The JS simulator is a great way to achieve systems testing.

System testing can also be achieved by exporting test interview data as .dat files and looking at the size of the individual dat files: you will be able to measure the load that will incur on memory. Multiply this by the number of concurrent interviews you expect and you will have an idea of the specs you need on your server(s). Additionally, looking at the size of a .QES file or preferably of the tables generated in SQL server will indicate how much Hard Drive space you will need.

Random Data Generation in askiatools

We have recently added a lot of features to the Tools random data generator: you can define routings that would only be run during random generation (for validating the screening for instance), you can specify the behaviour when blocking error messages are displayed and more importantly you can import your quota settings and take them into account in your generation (all available in 5.3.3). Quota code is often complex and going over could be an expensive mistake.

We have also created a brand new module in Tools 5.3.5 called “Verification scripts” (see here for more details). This allows a tester – remember not the survey scripter – to create checks in AskiaScripts that will be run on each interview. So you can verify that the question about credit cards has been asked if the interviewee has mentioned banks in another question. You simply write a check like this:

Assert.Check( Banks <> {} and CreditCards.HasNA,” Interviewee should have been asked the question about credit cards” )

The scripts can be as long as you like, we have added If Else conditions and Goto to help you create complex code that you will keep in one single text file. And you can write it within an environment – the askia visual studio – where you get help and documentation on any objects, methods or keywords. You can run this on your randomly generated data, on your soft launch or on your full data set – each time you get a detailed report of how many checks have failed. At the time of writing, this is not released yet but contact us if you want to try a beta.

In these scripts, we also want to have access to aggregated data… this will allow us to have one script that runs interview level testing and aggregated testing. We might want to test if an interview took less than 10% of the average length or if a given response to a question is outside a percentile. In other words, you might want to compare interview responses not with other interview responses but all other interview responses. The script grammar for this will be described in a forthcoming article – we are still passionately discussing it internally.

Usability testing in survey design by Askia

We have not covered usability testing here – not that we do not think it’s important: we are constantly talking about it internally. We are putting together a range of tools for designing ADCs (so far codenamed ADCUtil – yes we need something catchier), we have added ways of visualising your HTML in other browsers in Design. But we need to understand when a display no longer works because of screen size, the bias triggered by no longer using JavaScript, count the number of heads of Internet Explorer 5 users – and there again we need your input and your ideas so we can automate these tasks.

In the meantime, I leave you with these great quotes:

The act of maintaining software necessarily degrades it.” – Alain April

It’s harder to read code than write it.Joel Spolsky

If you can’t measure it, you can’t improve it. Peter Drucker
